Description

60 mm Light Commando Mortar is designed for destructive kinetic impact against enemy combat systems and to destroy manpower, light field fortifications as well as firearms and military technology with semi-indirect fire. Due to the high range and high fragmentation of the projectile, the mortar provides effective support to the fighting units under different optical visibility and atmospheric conditions both during the day and at night. The steep trajectory of the missile and the small dimensions of the mortar in the combat position allow the targets to be struck by semi-indirect fire, i.e. observed from the firing position.

LMC manufactured by ZM Tarnów S.A. is the only mortar on the market that allows to fire projectiles up to 2.2 kg while ensuring the guaranteed durability of the barrel at the level of 2000 shots. The LMC mortar is designed to fire 60 mm MAPAM (Mortar Anti-Personal Anti-Material) ammunition with a propellant charge I (Charge 1) by SAAB Bofors Dynamics. The LMC mortar is equipped with a built-in programmable digital sight with the display of the distance to the target and display of angular values, which enables to fire other 60 mm rounds with a caliber compliant with the STANAG 4425 ed. 2 of any manufacturer under the condition that the propellant is limited to the permissible pressure value and the digital sight is reprogrammed to implemented compatible shooting tables.



Gallery

Technical data

Barrel caliber	60.7 mm
Length	850 mm
Height	230 mm
Maximal range	min.1300 m
Minimal range	max. 110 m
Shot angle range for the scope	45° ÷ 85°
Weight	≤ 7.5 kg
Maximum pressure of gunpowder gases in the barrel	28±2 MPa
Rate of fire without correcting the aiming	25 rds./min
Rate of fire with improved aiming rounds	10 rds./min
Maximum number of rounds fired by continuous fire	30
Recommended service	2 operators
Minimum service	1 operator
Sight	digital
